The switchgear and
power distribution system
for the VX25.



The VX25 Ri4Power allows you to create different sections within a switchgear
or power distribution system to perform these tasks.

Explore now

ACB section

For feeding and outputting large currents into and from the switchgear. Air circuit-breakers are used to protect people and machines.

Outgoing section

For installing circuits with switchgear, power supply outlets, controllers, switchgear units, fused outgoing feeders and much more. This allows circuits and controllers to be combined under one roof.

Fuse-switch disconnector section

For compact, variable distribution of electric power with fused switchgear. Plug-type NH slimline fuse-switch disconnectors are used here, supported by vertical multi-terminal busbar systems.

Cable chamber

For distributing cables and lines leading into or out of compartments, to provide cable management for outgoing sections. Cable entry is optionally from above or below.

Energy storage section

The infrastructure solution for battery energy storage solutions (BESS): The modular system allows you to compile enclosures from Rittal standard components that are tailored to the individual storage system.

Form 2b

As effective protection against accidental contact with the busbar. Designed as an internal sub-division of the busbar compartment against the functional space and connection space.

Coupling section

For disconnecting or connecting different busbar systems within low-voltage equipment. Also for maintaining machine and plant uptime, because individual sub-sections may be disconnected separately.
feldtypen_1920x945-2

fri190403200

Maximum performance

The stabilisers mounted between the horizontal rails of the air circuit-breaker significantly improve short-circuit resistance.
fri190402900

Stability

The stabilisers mounted between the horizontal rails of the air circuit-breaker significantly improve short-circuit resistance.
fri190403000

Fast assembly

The mounting bracket for the air circuit-breaker support rail is attached directly to the enclosure frame section. A fast, simple and stable solution which is very easy to assemble.
fri190402200_1920x945-2

ACB section

FOR PROTECTING MACHINES AND SYSTEMS

Air circuit-breakers protect machines, plant and people from damage and injury associated with short-circuits, earth faults and overloads.



  • The VX25 Ri4Power is suitable for use with open and compact circuit-breakers from all well-known manufacturers, including ABB, Eaton, General Electric, Mitsubishi, Schneider Electric, Siemens, LSIS and Terasaki.

  • Modular continuity and exceptional manufacturing quality guarantee exceptionally time-saving assembly.

  • Up to 6300 A, the busbar systems are dimensioned to your specific requirements with standard copper bars and individually configured.

  • Plan and prepare efficiently with the Rittal Power Engineering Software.
fri190403500-1

Multi-functional

The functional space divider will fit any section type. Benefits: Fewer components, high efficiency. The air-permeable grille supports thermal convection across the entire section, ensuring improved pressure equalisation throughout the functional space.
fri190405000-1

Flexibility

The embossed knock-outs in the functional space dividers may be removed without burrs, for flexible division of the openings depending on the planned cable routing and for a seamless, direct power supply to the control and wiring sections.
fri190402700_1920x945

Outgoing section

FOR COMBINING SWITCH AND CONTROL FUNCTIONS

In the outgoing section, many different components may be connected under one roof, such as power distributors with control units. Individual functional spaces, shielded from one another, are created within the section to achieve this.



  • Targeted configuration and bespoke population, e.g. with switchgear, power supply outgoing feeders or control units.

  • Distribution busbar system with versatile positioning options, easily and securely connected to the main busbar systems using system components.

  • Modular enclosure busbar system spanning different sections and functional spaces.
fri190403900

Fast assembly

Component installation and finger-proof shielding is achieved by simply screw-fastening; no drilling required.
fri190404200

Components

Form 2b perfectly complements the purpose-designed 185 mm components. Example: NH slimline switch-disconnectors with fuses for operator-independent disconnection and switching.
fri190404000

Fast attachment

The busbar support is secured to the enclosure section using just two screws. An embossed knock-out is provided so that a matching cut-out can be made quickly in the compartment side panel.
fri190402500_1920x945

Form 2b

TO ENSURE OPTIMUM CONTACT HAZARD PROTECTION

The Form 2b designed as an internal separation shields the busbar compartment from the functional space and the connection space.



  • All active parts are safe from finger-contact in line with IP 2X.

  • When working in the functional space, connection space or busbar compartment, the modular, width-flexible cover provides effective protection from contact with the busbars.

  • Shielding to Form 2b also protects the equipment by preventing the unwanted ingress of foreign bodies into the busbar compartment.

  • Convenient plug-in and clip-in technology supports simple assembly of all components with no drilling required.
fri190405800

Independence

The main busbars may optionally be routed in the roof section or central rear section.
fri190404900

Modular benefits

The coupling set power infeed towards the roof section is always based on the same riser at the side. It is always identical, regardless of whether it is integrated into a coupling section or accommodated in another enclosure as a separate section.
fri190402300_1920x945

Coupling section

TO MAINTAIN FAIL-SAFE OPERATION

A combination of an air circuit-breaker section with a busbar riser optionally arranged on the left or right.



  • Individual sections of busbar can be de-energised without switching off the entire system, to prevent malfunctions and total failures.

  • With the VX25 Ri4Power, busbar sections may be safely disconnected thanks to comprehensive, stable partitioning, which allows the stringent requirements for overall short-circuit resistance to be reduced.

  • Similar layout as with the air circuit-breaker section. The system synergies help to significantly reduce assembly time and offer major cost-saving potential.

Universal benefit

One single section type is sufficient for all horizontal fuse-switch-disconnector types.
fri190404800

Planning confidence

The positioning of the vertical section is identical for all fuse-switch-disconnector types. In this way, the system can be fully planned and implemented regardless of which fuse-switch-disconnector manufacturer is subsequently chosen.
fri190402600_1920x945

Fuse-switch disconnector section

FOR A RELIABLE POWER SUPPLY

For compact, variable distribution of electric power with fused switchgear. Plug-type NH slimline fuse-switch disconnectors are used here, supported by vertical multi-terminal busbar systems.



  • Fast, secure, complete preparation for installing NH slimline fuse-switch disconnectors.

  • Interchangeable control units may be integrated into the fuse-switch disconnector section even when live.

  • The main and distribution busbar system may be configured for a short-circuit resistance of up to 100 kA for 1 sec.

  • The internal separation in the fuse-switch disconnector section is tailored to the customer’s requirements.
fri190404600

Combination benefits

The fuse-switch disconnector section is available with integral cable chamber, fully pre-configured, including partitioning. No additional accessories are required. Benefits: Space-efficient and time-saving.
fri190402600_1920x945_02

Cable chamber

FOR DISTRIBUTING CABLES AND LINES

The cable chamber is used for routing cables and lines to the functional spaces.


  • Exceptionally time-saving, flexible installation thanks to the extensive range of VX25 Ri4Power system accessories.

  • Depending on the main busbar system chosen, cable routing may be either from below, above, or below and above.

  • Choose from a range of cable entry glands for the roof plate.

Modular

The battery rack with heavy-duty shelves can support a load of 100 kg per shelf, up to a maximum load of 1,500 kg. The design allows the flexible integration of different battery types into the rack. They may be contacted directly onto the busbar system. There is plenty of space in the roof section for battery management. Baying is straightforward and achievable at any time, for scalable storage capacity.

482.6 mm (19") enclosure

The battery rack with 482.6 mm (19") installation likewise supports loads of up to 1,500 kg. Depending on the rack height, up to 42 U is available for the use of 482.6 mm (19") modules, which may be contacted directly onto the busbar system. There is plenty of space in the roof section for battery management. Baying is straightforward and achievable at any time, for scalable storage capacity.
fri190402400_1920x945

Energy storage section

FOR SUPPLYING POWER RESERVES

ESS is a modular infrastructure solution for battery energy storage solutions (BESS).



  • Together, Rittal standard components form a modular system which is used to configure bespoke enclosures.

  • Depending on the manufacturer and design of the storage modules, the enclosure layout may be flexibly modified, for example with individual connection options.

  • This very assembly-friendly solution allows easier rack scaling, power distribution, cooling and system configuration, thus helping to safeguard system availability.

  • For seamless monitoring of performance and risk of failure, ESS may be combined with CMC and RiZone for the monitoring system.  Web connectivity is provided via the Rittal IoT module.
Design benefits
fri190404400(1)

Copper savings

Standard bars are available in 30 x 10 mm and 50 x 10 mm. The stable enclosure bar system and the arrangement of the bars support a higher current-carrying capacity with an identical copper bar cross-section.
Offene Schienenhalter

Fast attachment

The open busbar support can additionally accommodate the quick-release fastener for simple, fast connection to the next section.
fri190405400-1

Multi-functionality

The standard copper bars size 50 x 10 mm may also be used as neutral conductors.
fri190404300

Immediate machining

The standard copper bars size 50 x 10 mm are already pre-punched and cut to length, to match the enclosure widths. They may be fitted directly without machining.
fri190403600

Reduced number of parts

The 25 mm pitch pattern allows top busbar supports to be mounted directly onto the enclosure section. Just three screws is all you need. No further components are required.
fri190405300

Independence

The main busbars may optionally be routed in the roof section or central rear section for improved planning and space flexibility.
fri190403600_1920x945_kante-1

Benefits of the busbar system

The Ri4Power busbar system now boasts easier installation, thanks to a significant reduction in components with identical functionality, and is sure to impress.
fri190403500_365x

Complete partitioning

The compartment side panels to match the enclosure height provide effective shielding for all the functional spaces below. This replaces vertical individual partitions from section to section and reduces the number of components and assembly time required.
fri190405000-2

Adjustment

The embossed knock-outs in the functional space dividers may be removed without burrs, for flexible division of the openings depending on the planned cable routing and for a consistent, direct power supply to the control and wiring sections.
fri190403500 - Kopie

Flexibility

The 25 mm enclosure section pitch pattern and side panel perforations facilitate height-flexible, fast assembly of the horizontal compartment divider with minimal parts. They simply slide into position and are fitted in the same way as “back panels”.
fri190405600

Continuity

Connecting PE or N conductors by directly screw-fastening the bar supports with the frame section ensures an identical, consistent arrangement of bars in the rear or front enclosure area in all sections, whatever the type.
fri190403400-1

Straight lines

The pre-punched knock-outs in the compartment side panels allow PE and N conductors to be continued across sections and support straight-line routing through all section types.
fri190403500_1920x945_kante-2

Benefits of the interior installation system

The one-piece side panel and optimised functional space dividers ensure easier assembly, while pre-manufactured cut-outs simplify cable entry.
Rittal Power Engineering

Rittal Power Engineering

 FOR ENHANCED PLANNING CONVENIENCE



The Rittal Power Engineering planning software makes it much easier to configure section types and equipment. The connector kits are automatically generated and documented when this software is used for project planning.
