AX FIBERGLASS REINFORCED POLYESTER ENCLOSURES
Added durability

Discover our new non-metallic wallmounted enclosures. And experience the benefits of a unique enclosure series for yourself – Sophisticated system technology combined with an extremely robust material.

14 sizes available from stock, with or without viewing window
7 times higher UV protection for full outdoor capabilities
With all necessary certifications and approvals for worldwide use

Welcome to the AX family

AX. System perfection.

After more than 30 years, Rittal is revolutionizing the field of non-metallic enclosures and complementing its AX series of carbon steel and stainless steel enclosures. With the new AX Fiberglass Reinforced Polyester enclosure, Rittal has now combined the benefits of a sophisticated system technology with those of an extremely robust material to produce a unique enclosure series.

AX Fiberglass Reinforced Polyester enclosure provides maximum simplification, speed and configuration freedom, while at the same time meeting the highest demands in terms of safety and robustness. Installed indoors or completely exposed to the weather outdoors – the AX Fiberglass Reinforced Polyester enclosure will safely protect your electrical components.
The AX enclosure series defines the standards for Industry 4.0-compliant enclosure manufacturing.

AX FIBERGLASS REINFORCED POLYESTER ENCLOSURES

Get to know the benefits of the new AX non-metallic enclosure.

More safety
More efficiency
More flexibility

14 different enclosure variants, with and without viewing window, made from fiberglass-reinforced polyester with high UV resistance.
The mini-comfort handle for AX Fiberglass Reinforced Polyester can be used not only with type A lock inserts, but also with profile half-cylinders or security and push-button inserts.

Outdoor capabilities thanks to high safety standards

High level of safety for people and installed equipment
UL F1 outdoor rating (UL 746C) thanks to 7 times higher UV resistance
UL approval for industrial enclosures (508A)
Fire protection corresponding to UL 94 V-0
Smart enclosure design permits interior installation without impairment of the encapsulated space, i.e.
- retaining the high protection category up to IP 66/NEMA 4X
- retaining protection class II

Applications

Maritime industry

Extreme ambient conditions place particular demands on the material and surface properties of an enclosure. The AX Fiberglass Reinforced Polyester enclosure offers corrosion protection and is resistant to UV radiation, salt and salty air.

Wastewater management

Especially in this field, enclosures are exposed to various damaging influences, for example aggressive vapours which can attack the material. The AX Fiberglass Reinforced Polyester enclosure offers optimum protection – in the same way as against wind, weather and UV radiation.

Railway technology

Thanks to its robust material and stable construction, the AX Fiberglass Reinforced Polyester enclosure withstands aggressive environments, dampness and all arising pressure/suction forces.

Airports

The AX Fiberglass Reinforced Polyester enclosure withstands UV radiation, rain, snow and storm, and offers protection against flying debris such as tyre wear particles.

Optimised value-adding through digital networking

Integrated, consistent, data-based solutions spanning the entire value chain, from engineering, to system engineering, through to automation and beyond, are the key to greater efficiency in panel building and switchgear manufacturing. Act now to secure a better position in the competitive markets of the future.

Engineering tools

A wide range of conversion and planning tools are available to Rittal customers to support them with the automated production process and when working with a virtual prototype:

Configurators
EPLAN Pro Panel data
2D/3D CAD data
ecl@ss Advanced Daten
Technical documentation
Data for planners
'How-To' videos

Direct integration of climate control

Solutions to suit all ambient conditions
High protection categories are retained

Safe incorporation of power distribution

RiLine Compact

Shock-hazard-protected busbar system based on an innovative board technology.
Ideally suited for compact plug-in switchgear applications.
Fast component and equipment replacement provides for a high level of system availability and short recovery times.

Milling centre Perforex BC

Milling centre Perforex BC The drilling and milling centres in the Perforex BC series allow you to machine any material, including spray-finished sheet and stainless steel as well as aluminium, copper and the new AX fiberglass reinforced enclosure.

Fully automatic drilling, tapping and milling of panel parts and enclosures
Faster throughput times at the machining stage
Unbroken data flow from engineering to the machining centres
High precision and repeat accuracy

Engineering

Engineering is the starting point for every panel building and switchgear engineering project. With the help of software tools developed by Rittal and Eplan, a virtual prototype of an enclosure is created. It contains all the information relevant for the production process, enabling maximum efficiency at every point in the workflow. In this way, seamless data allows you to create and benefit from automated production processes.

System

Enclosures, power distribution, climate control. Enclosures do not exist in isolation, but are part of a bigger, multi-faceted system. The Rittal modular system offers coordinated solutions covering every requirement – fast, flexible, and worldwide. Capitalise on unique system solutions with clear benefits for users.

Automation

Inside the enclosure workshop, workflows can also benefit from digitalisation and extensive automation. The machines and tools from Rittal Automation Systems support every aspect of machining and component mounting in panel building, from individual machining of enclosure panels through to fully automated wire assembly. Act now and create the basis for automated processes in your workshop.
